在當下工業生產注重高效與空間利用的時代，伸縮式噴漆房的出現滿足了大型工件噴漆作業的需求，許多企業在處理大型工件噴涂時需要靈活調整作業空間，這時伸縮式噴漆房的優勢便充分展現出來。不過設備使用一段時間后，總要進行一些必要的檢查。接下來就為大家介紹伸縮式噴漆房的檢查方式。

　　In the current era where industrial production emphasizes efficiency and space utilization, the emergence of telescopic spray painting rooms has met the needs of large-scale workpiece spray painting operations. Many enterprises need to flexibly adjust the working space when handling large-scale workpiece spray painting, and the advantages of telescopic spray painting rooms are fully demonstrated at this time. However, after using the device for a period of time, it is necessary to conduct some necessary checks. Next, we will introduce the inspection method of the telescopic paint booth.

　　開機檢查：

　　Power on inspection:

　　伸縮式噴漆房啟動后，要檢查框架傳動系統的運行狀態，運行時的噪音應較小，且沒有異常聲響。驅動電機及傳動部件運行要穩定可靠，溫度應≤環境溫度 + 70℃。各連接部位的潤滑情況應良好，若潤滑不足需及時補充。軌道與滑輪配合應順暢無卡頓。

　　After the retractable paint booth is started, the operation status of the frame transmission system should be checked. The noise during operation should be low and there should be no abnormal noise. The operation of the drive motor and transmission components should be stable and reliable, and the temperature should be ≤ ambient temperature+70 ℃. The lubrication of each connecting part should be good, and if the lubrication is insufficient, it should be replenished in a timely manner. The coordination between the track and pulley should be smooth and without any jamming.

　　停機檢修：

　　Shutdown maintenance:

　　打開檢修口檢查各傳動部件的潤滑狀況與磨損程度，潤滑油應沒有雜質、不發生變質。若存在雜質需及時更換，潤滑部位的油量控制在合理范圍。檢查兩側驅動裝置的同步性，確保運行時不會出現卡頓或偏移，傳動鏈條或皮帶應無斷裂、保持完好。檢查軌道是否存在變形或異物，確保無嚴重磨損。查看阻燃 PVC 布的密封情況，確保無破損漏風。檢查防爆照明燈的線路連接是否牢固。查看房體框架有無破損和變形。檢查安全限位裝置是否靈敏有效。

　　Open the inspection port to check the lubrication condition and wear level of each transmission component. The lubricating oil should be free of impurities and not have deteriorated. If there are impurities, they need to be replaced in a timely manner, and the amount of oil in the lubrication area should be controlled within a reasonable range. Check the synchronization of the driving devices on both sides to ensure that there is no jamming or deviation during operation, and that the transmission chain or belt is intact and undamaged. Check for any deformation or foreign objects on the track to ensure there is no severe wear. Check the sealing condition of the flame-retardant PVC cloth to ensure no damage or air leakage. Check if the wiring connection of the explosion-proof lighting is secure. Check if the frame of the house is damaged or deformed. Check if the safety limit device is sensitive and effective.

　　關鍵部件細致檢修：

　　Detailed maintenance of key components:

　　拆下驅動電機的固定螺栓，將電機與傳動機構分離開來。拆下軌道固定件，清理軌道內的雜物。用專用工具檢查傳動齒輪或鏈輪的嚙合情況，必要時進行調整。檢查阻燃 PVC 布與框架的連接部位，更換老化或破損的連接件。拆卸過濾裝置的固定部件，取出過濾材料進行清潔或更換。檢查風機及風道的運行狀況，清理內部積塵。用清潔劑擦拭房體內壁，檢查密封膠條的完好性。

　　Remove the fixing bolts of the drive motor and separate the motor from the transmission mechanism. Remove the track fasteners and clean the debris inside the track. Use specialized tools to check the meshing of transmission gears or sprockets, and adjust them if necessary. Check the connection between the flame-retardant PVC cloth and the frame, and replace any aging or damaged connectors. Disassemble the fixed components of the filtering device, remove the filtering material for cleaning or replacement. Check the operation status of the fan and air duct, and clean the internal dust accumulation. Wipe the inner wall of the room with a cleaning agent and check the integrity of the sealing strip.

　　伸縮式噴漆房憑借適應性強、空間利用率高、成本合理等優勢，被廣泛應用于汽車制造、重型機械、船舶修造、大型設備生產、五金加工等多個行業領域。

　　Due to its strong adaptability, high space utilization, and reasonable cost, the retractable spray painting booth is widely used in various industries such as automobile manufacturing, heavy machinery, shipbuilding, large-scale equipment production, and hardware processing.
